Automatic Pail can line
Automatic Single slitter
Dimension :6000x1600x1800mm
Motor power : 5.5KW, 380,50/60HZ
Cutting size Max : 1050x1050mm
Cutting size min : 350x350mm
Speed : 50 pieces per min
Total weight : 5000 kgs
Inside Powder Coating Machine
Conveyring speed :12-60m/min
Speed : 20-80 pcs/min
Coating width:8-12mm
Can diameter :52-280mm
Powder type : epoxy resin
Outside Roller Coating and drying machine
External coating and drying machine
Coating outside width :12mm
Coating Inside width :12mm-13mm
Coating speed :6-30 m/min
Coating manner : Roller coating (Automatic glue-feeding)
Automatic leakage tester
Can Capacity:10-25L
Height:80-380mm
Testing Accuracy:0.12-0.15mm
Line Speed (CPM):35
Head Quantity / Stations:18
Automatic Rectangular can line
GT1B5 Slitter machine
Name:Gang Slitter/Cutting Machine
Max sheet thickness: 0.4mm
Max sheet width: 1050mm
Min sheet width: 44mm
Motor power: 1.1kw
CY400-AT
Capacity: 10-45cans/min
Applicable can diameter: 70-450mm
Applicable can height: 99-300mm
Applicable material: tinplate
Applicable material thickness:0.15-0.42mm
Fb2000-B
Welding speed:6-12m/min
Capacity:20-50cans/min
Diameter:￠180-300mm
Height:200--450mm
LS-B
Water Chiller ;
Used for cooling the welder machine to make it be a longer uselife time.
3FB4J Flanging machine
Capacity:17-20cans per minute
Range:1-4L
Net weight:750kg
Motor power:1.5kw
Dimension: 850X1020X800mm
4A19FQ pneumatic seamer
Capacity : 20cpm
Range :1-4L
Net weight : 850 KGS
Motor power : 2.1 kw
Dimensions : 1200x850x780mm
Conveyor
Width of belt : 240mm
Power :Y802-4B3- 0.5 KW
Net weight : 550 kgs
Dimension : 1200x550x300mm
Can lid lining machine
Can lid size : 1-4 L
Speed :40 cpm
Motor power : 2.1 kw
Dimension : 1200x1550x800mm
Weight :700 kgs
DN-40Z
Can size : 1L-4L
Air compressor : 900L/min;0.5Mpa
Thickness of metal base : 0.35-0.45mm
Speed : 20 cpm
Motor power :380V,50HZ 50Kva
Press machine 25 T
Nominal forece : 250kn
Slide block stroke:55mm
working table dimension:400x600
Motor power:2.2kw
Weight :1900 kgs
Press machine 16T
Nominal forece : 160kn
Slide block stroke:55mm
working table dimension:400x600
Motor power:2.2kw
Weight :1900 kgs
Square end line
MC1S-80
Nominal stroke:5
Slide stroke: 150 mm
SPM: 50-70 min
Max Die height :340mm
Die Height adjustment:80mm
Pail bottom curling and lining machine
Can size : 15L square lid ,4L lid
Air compressor : 900L/min;0.5Mpa
Thickness of metal base : 0.35-0.45mm
Speed : 25-30 cpm
Motor power :380V,50HZ 50Kva
Automatic round can line
Automatic Single slitter
Sheet thickness: 0.12-0.4mm
Max stacking height of tin: 480mm
Motor power: 10kw
Compresses air:0.6Mpa 0.2m³/min
Max loading weight of tin: 3000kg
Outside Roller Coating and drying machine
Coating outside width :12mm
Coating Inside width :12mm-13mm
Coating speed :6-30 m/min
Coating manner : Roller coating (Automatic glue-feeding)
Coating machien dimension :2100x820x1800mm
High Frequency induction oven
Conveyor speed:5-30m/min
Conveyor type:Flat chain drive
Can height range:120-250mm
Heating type:Induction
Effective heating:800x8(60 cpm)
Automatic square can line
Automatic Single slitter
Motor power : 5.5KW, 380,50/60HZ
Cutting size Max : 1050x1050mm
Cutting size min : 350x350mm
Speed : 50 pieces per min
Total weight : 5000 kgs
High Frequency induction oven
Conveyor speed:5-30m/min
Conveyor type:Flat chain drive
Can height range:120-250mm
Heating type:Induction
Effective heating:800x8(60 cpm)
Square can body forming machine
Dimension : 5 gallon square can
Height : 175-400 mm
Speed: 28-30 cpm.
Motor power : 15 KW.
Dimension : 15400x3100x1500mm
Weight : 15000
Automatic leakage tester
Height:80-380mm
Testing Accuracy:0.12-0.15mm
Line Speed (CPM):35
Head Quantity / Stations:18
Total power:3KW
Pail top line
MC1S-80
Nominal stroke:5
Slide stroke: 150 mm
SPM: 50-70 min
Max Die height :340mm
Die Height adjustment:80mm
Pail bottom curling and lining machine
Used for Curling and lining the bottom
Speed : 40 cpm
Diameter :270-320mm
Vertical Drying machine :
With cooling zone. Input 4 covers.
Total length :1200x950x5100mm
